vTelemetry PRO delivers real-time data logging, multi-lap comparison with overlay technology, advanced math channels, optional video capture, and a fully configurable analysis environment. With up to 104 telemetry channels, vector-based GPS mapping, high-rate recording, and multi-instance analysis, it is built for precision, speed, and clarity.


Available in multiple software stages up to the Motorsport Edition for maximum data depth.

Designed for simulator environments

The vTelemetry PRO architecture supports two configurations:

• LOCAL: Server and client installed on the same PC.
  REMOTE: Server installed on the simulator PC, client installed on any device on the same LAN.

The server app runs in the background, bridging racing simulators/games with the client via TCP/IP.

Your central workspace

The client app is the core of vTelemetry PRO and includes:

• Data Logger for real-time data acquisition and visualization
• Multi-instance analysis tool for comparing multiple laps using overlay technology
• Management of optional 60 fps video capture

The Data Logger acquires up to 104 channels, including:
driver inputs, chassis and suspension data, brakes, tyres, engine, wheels, hybrid systems, 3-axis G-Force and a GPS-based circuit map.

• Records telemetry up to 330 Hz (207.2K samples/sec)
• Graph rendering: 60–300 fps for smooth real-time tracking
• Full post-processing playback
• Synchronized with optional video capture

Deep analysis. Clear insights.

• Compare up to 7 laps per analysis window
• Run up to four analysis windows simultaneously
• Fully customizable graphs, channels, and x-axis controls
• Overlay multiple laps for instant visual comparison

Create custom telemetry channels

Generate new channels using simple or complex mathematical expressions based on existing telemetry data. Fully integrated into analysis tools.

Export telemetry sessions to PDF, XPS, or paper.

Printouts can include custom company information where available.

Additional displays (where supported) include:

• Advanced Tyres Monitor
• G-Force Gauge
• Driver Input Display
• Circuit Map with GPS
• Dashboard/DDU Display
• Balancing Gauge
• Hybrid Monitor

Add system or user markers directly to graphs during recording or post-processing.

Options include message text, color, style, position, and lap-specific configuration.

Import and export full sessions or single laps using CSV.

Preset converters for: AIM, ATLAS, MoTeC, Pi Toolbox, Wintax.

Allows comparison between real-car and simulator telemetry on one platform.

Regularly updated compatibility:

• Assetto Corsa
• AC Competizione
• Assetto Corsa PRO (Optional)
• Automobilista
• F1 2017–2022
• iRacing (Updated)
• Project CARS 1 & 2
• RaceRoom (R3E)
• rFactor 1 & 2
• rFactor PRO (Optional)

Precision tools for professional analysis

• Real-time data recorder with live visualization
• Reference lap (auto/manual)
• Multi-lap comparison with overlay
• Up to 104 telemetry channels
• GPS track map
• LAN networking with integrated server
• Lap timing with sectors
• Delta time relative to reference or fastest lap
• Optional Ultra HD 60 fps video capture
• Fully customizable interface with 60,000+ style combinations

• Windows 7, 8, 8.1, 10, 11 (32/64-bit)
• Microsoft .NET Framework 4
• Intel Core i3 1.60 GHz or better
• 2 GB RAM (DDR3 or higher)
• AMD Radeon HD 6450 / Nvidia GeForce GT 460 or higher
• 50 MB disk space
• CD/DVD optical drive
• Free PCIe/USB 3.0 port for video capture
• Internet connection for activation/updates
• LAN (Ethernet or Wi-Fi) for remote acquisition

Provides detailed lap time lists with sectors and delta calculations.
